Description
Specifications
- Flow Characteristics
- Equal percentage, Linear, Modified Equal Percentage, Special Characterization
- Material
- 304 Stainless Steel, 316L Stainless Steel, 316 Stainless Steel
- Operating Temperature
- Cryogenic
- Pressure Class
- PN, ASME
- Shutoff Class
- Class V (FCI 70-2)
- Valve Size
- NPS 3, NPS 4 / DN 100
- Valve Size Standard
- DN, NPS
- Valve Type
- Angle Valve
Features
- Fabricated construction
- High quality stuffing box with PTFE Chevron rings
- Variable nozzle type
- Wide range of Kv (Cv) available
- Special nozzle combinations available
- Yarway pneumatic actuator available
- Wide choice in positioners and other actuator ancillaries
- Pressure class and connections: ASME B16.34 class 150 thru 900, DIN 2401 Class PN 25 thru PN 100
- Materials: ASTM-A 312 TP 316 (L) and 304 (L), ASTM-A 182 F316 (L) or 304 (L), Other materials on request
